    50L Stainless Steel 304 Concentration Tank Extraction Unit Extraction Concentrator

    Ask Lasest Price
    Brand Name : Lanphan
    Model Number : LPEC-50
    Certification : contact us
    Price : $16999/pc
    Payment Terms : L/C, T/T, Paypal...
    Supply Ability : 30 Units per Month
    Delivery Time : 7-15 days
    • Product Details
    • Company Profile

    50L Stainless Steel 304 Concentration Tank Extraction Unit Extraction Concentrator

    50L Stainless Steel 304 Concentration Tank Extraction Unit Extraction Concentrator

    Extraction Concentrator Feature

    1.Big heating area for concentration , high concentration efficiency , short time of concentration , difficult to deposit , easy cleaning . The middle storage tank , attached to the set and beneath the evaporator , can make residue output and next batch of extraction , and during the same period , the concentrator can finish concentration of extraction liquid and prepare for next batch of extraction .
    2.The condensation area is benefit to condensation and recovery of solvent , with low loss to solvent and a recovery rate of 95% and above
    3.Fruitful energy saving and full utilization of residual heat to reduce repeated heating and cooling, lowering energy consumption.
    4.Multi-function , compact structure , small floor area , low need to operator , low investment and production cost .
    5.Full enclosed production by pipe to reduce the contamination to environment , in compliance with GMP .

    Extraction ConcentratorDescription

    This equipment is an electric heating extraction unit with functions such as heat reflux, water extraction, aromatic oil, normal pressure extraction, vacuum concentration normal pressure extraction, and cream collection.

    50L Stainless Steel 304 Concentration Tank Extraction Unit Extraction Concentrator

    Extraction Concentrator ​Applications

    50L Stainless Steel 304 Concentration Tank Extraction Unit Extraction Concentrator

    Extraction Concentrator ​structure

    50L Stainless Steel 304 Concentration Tank Extraction Unit Extraction Concentrator


    ModelEC-50
    Extraction Tank/
    Concentration Tank
    Volume (L)50L
    Heating TemperatureRt-150℃
    Heating Power6KW/12KW
    Stirring Speed23rpm
    Motor Power(KW)1.5KW
    Filter Fineness73um
    FilterFilter Fineness25um
    Whole MachineVacuum Degree-0.09Mpa
    MaterialSS304
    Health LevelGMP
    Total power27KW
    Supply Voltage380V/50Hz-3P
    Package Dimension2360*960*2235mm
    Package Weight688kg

    Extraction Concentrator ​Details

    50L Stainless Steel 304 Concentration Tank Extraction Unit Extraction Concentrator50L Stainless Steel 304 Concentration Tank Extraction Unit Extraction Concentrator
