Short Path Distillation Equipment Molecular Essential Oil Extraction Distiller 20L Lab

Short Path Distillation Equipment Description

Basic constitution: The column cylinder is equipped with outside heating mantle, rotor and inside condenser. The fixing frame of rotor is precisely equipped with scratch film and anti-splash device. The inside condenser is placed in the center of evaporator, and the rotor should rotor between column cylinder and condenser.

Distillation process: The material should add from the top of evaporator and continuously spread to the heating surface through the material covered on rotor. Then, the scratch film is capable of scratching the material into a thin and flowing liquid film. During this process, the light molecular exceeded the heating surface form the condense liquid on inside condenser without any collision. Then, the molecular flows along the condenser tube, and discharge through the discharge tube on the bottom of evaporator. The residue liquid (heavy molecule) is collected on the circular channel under the heating zone, and flows through the discharge tube on one side.

Short Path Distillation Equipment Detail

Adopt three ports reaction bottle, with a special feeding port, which is convenient for feeding.

Micro vertical spine distiller, vertical spine structure, used for fractionation function; Vacuum sandwich is used to weaken the influence of wind and greenhouse, so as to maintain the appropriate temperature gradient in the column.

Vacuum valve can be equipped with the micro vertical spine distiller, used for vacuum pumping.

Glass parts are connected by frosted mouth, which is easy to operate and has good sealing. Plastic clip is fixed and avoid loose interface.

Short Path Distillation Equipment Principle

As a type of thermodynamic separation technology, the equipment can evaporate components with low boiling points by utilizing that the boiling point of each component in the mixed liquid or liquid-solid mixture is different, and then condense the material to separate the whole components. It is the combination of evaporation and condensation unit operations as well as a kind of liquid-liquid separation technology.

Short Path Distillation Equipment Parameter

Short Path Distillation Equipment

Henan Lanphan Industrial Co., Ltd. integrates industry and trade.

The company has advanced production equipment, excellent workforce, stable domestic and foreign partners.

The company has a number of outstanding employees with a bachelor's degree or above and a TEM-8 English major. The company's after-sales personnel have overseas master's degrees. Professional technical personnel provide strong backing for the company.

Henan Lanphan Industrial Co., Ltd. currently mainly sells two categories of products:

Scientific research instruments: rotary evaporator, glass reactor, vacuum pump, drying oven, magnetic stirrer, heating jacket, short-path distillation, centrifuge, falling film evaporator, molecular distillation equipment, etc.;

Piping equipment: rubber joints, metal joints, air duct joints, etc.;

Henan Lanphan Industrial Co., Ltd. occupies a leading position in the industry with high-quality products and reasonable prices. Products are exported to more than 100 countries and regions, with customers all over the world, and have won the trust of domestic and foreign customers with a good reputation.

The company adheres to the concept of "people-oriented", respects customers, employees, partners, suppliers and social groups; takes integrity as the purpose of the company's development, "honesty" is the foundation, and "trust" is used; the pursuit of excellence and continuous innovation.
