Low Temperature 3850w Cryogenic Liquid Lab Chiller Unit

Ask Lasest Price
Brand Name :	Lanphan
Model Number :	DLSB-50L
Supply Ability :	1000 Set/Sets per Month
Price :	$2,424.00

Add to Cart

Product Details
Company Profile

Low Temperature 3850w Cryogenic Liquid Lab Chiller Unit

Low-Temperature 50L Cryogenic Liquid Pump Coolant Machine

The capacity of our pump can be 5L-500L
Temperature ranges from room temperature to -120 degrees

Product Description

Low Temperature 3850w Cryogenic Liquid Lab Chiller Unit

The DLSB 50L-30℃ series low temperature coolant circulation pump is a low-temperature equipment that uses a compressor for mechanical refrigeration.

The water circulating pump is added to enable the cooled liquid to pass through the pipeline for external and internal circulation, and can provide low temperature liquid for external equipment such as a double-layer glass reactor, an organic synthesis
device, a rotary evaporator, etc. It can also be combined with a rotary evaporator, a vacuum freeze drying oven, a water circulating vacuum pump, a magnetic stirrer and the like to perform multi-functional chemical reaction operations and drug storage at a low temperature.

The chiller can maintain constant current and pressure. The circulating fluid can provide cooling water to meet the requirements of temperature and water purity, for large equipment such as high purity metal, rare substance purification, environmental experiment and magnetron sputtering, vacuum coating, etc. It can also meet the cooling needs of electronic instruments, electronic probes, ultra-high vacuum sputtering instruments, X-ray machines, lasers, accelerating leveling lamp and other valuable equipment.

It is especially suitable for chemical, biological and physical laboratories that need to maintain low temperature and normal temperature conditions. It is an essential equipment for medical and health, chemical industry, food industry, metallurgical industry, colleges and universities, scientific research, genetic engineering, polymer engineering and other fields. ( The large-capacity low-temperature coolant circulation pump can be customized according to user needs.)

Low Temperature 3850w Cryogenic Liquid Lab Chiller Unit

type		DLSB 50L-30℃	DLSB 50L-30℃
Tank volume (L)		59.31	59.31
lowest no-load temperature(℃)		-30
Using temperature range (℃)		room temperature—-30
best temperature range(℃)		≤25
Environmental relative humidity (%)		≤70
Working power supply (V/HZ)		single phase 220V 50HZ	three phase 380/50
temperature display mode		liquid crystal
temperature stability(℃)		±2
Sensor index		Pt100
Instrument adjusting range (℃)		±150
set way		Arbitrary adjustment of Settings in the range of use
safety protection		delay,leakage,over current,over heat
	10℃	4190	5475
Output refrigerating capacity(w)	0℃	3354	4380
	-10℃	2236	3285
	-20℃	1397	1190
	-30℃	559	1095
Total machine power (W)		2930	3850
Machine current (A)		13.8	5.4
refrigerant		R404A	R404A
	Power(W)	100	100
circulating pump	Flow rate(L/min)	25	25
	lift(M)	7	7
Opening size(mm)		360×360	360×360
tank shape
internal diameter and height of liquid storage tank(mm)		390×390×390	390×390×390
overall appearance size(mm)		760×615×1130	760×615×1130
machine weight(kg)		97	97

Low Temperature 3850w Cryogenic Liquid Lab Chiller Unit

Turn on and off:
The right turn to turn on the machine: Add the appropriate medium—connect the power with the special power supply—turn off the circulation switch—press the power button—open the circulation switch—open the refrigerator switch—open the cooling equipment
The right turn to turn off the machine.Turn off the cooling equipment—turn off the switch—turn off the circulation switch(stirring switch)—turn off the outlet valve(or discharge the cooling medium)—turn off the power supply —disconnect circuit breaker—disconnect the power line from the power supply—clean the equipment.

Corollary Equipment

Low Temperature 3850w Cryogenic Liquid Lab Chiller Unit
